Horizortal Scroll Discharge filtration Centrifuge >> Horizontal Scroll Discharge Filtration Centrifuge




Horizontal scroll discharge filtration centrifuge is designed for the solids/liquid separation according to the filtration theory. It is capable of separating solid particles from liquid within the size range of 0.05~3mm or dewatering effectively. It also provides washing function. This centrifuge features optimal separation behavior which thanks to its consistent operation, automatic discharge, efficient solids-liquid dewatering, convenient manipulation and maintenance, and less space occupation. It can reduce greatly the cost of drying and even eliminate this process under some special circumstances. By using the wear-resistant material, this machine can protect the wearing parts. As a result, this centrifuge is broadly used in today's industries such as chemical engineering, food, synthetic fibers, the metallurgy of mineral, and the pharmaceutical and light industries.


Main Specifications

Model

Bowl

Diameter

(mm)

Max.

Revolution

(r/min)

Separation

Factor

Production

Capacity

(m3 /h)

Max. Solid

Discharge Rate

(kg/h)

Motor Power

(kw)

Weight

(kg)

Contour

Dimensions

(mm)

LWL350×280

350

3,000

1,76

1~6



1,000

11

900

1,000×1,200×950

LWL450×300

450

2,300

1,330

3~10

2,000

15

1,100

1,943×1,259×1,262

Click count:3551  Input time:2010/6/10 【Print Page】 【Return
